一、功能介绍  Function introduction

①此设备用于全自动杯型口罩生产线(典型型号如N95口罩),设备整卷上料,多层水刺布，溶喷布，无纺布料卷经过 热压成型，重叠冷压，PU超声波焊接熔合,最终口罩裁切成型,自动贴鼻梁,自动耳带焊接出成品。

生产口罩具有佩带舒适,无压迫感,口罩过滤效果好,契合人的脸形,可以适用于医疗,电子,矿业,建筑等行业.

This equipment is used for automatic cup mask production line (typical model, such as N95 mask). The equipment is used for feeding the whole roll, multi-layer spunlace cloth, dissolving spray cloth and non-woven fabric rolls through hot pressing, overlapping cold pressing, ultrasonic welding and fusion,automatic pasting of foam, and finally cutting and forming the mask, automatic hot pressing of nose bridge and automatic welding of ear straps into finished products. The production of masks is

comfortable to wear, no sense of pressure, good filtering effect, fit the shape of human face, can be

applied to medical, electronics, mining, construction and other industries.

②本机采用PLC、触摸屏控制、主传送带采用进口伺服电机输送、，传动精确，控制稳定，速度可调。

This machine adopts PLC, touch screen control, main conveyor belt adopts imported servo motor transmission, accurate transmission, stable control, adjustable speed.

二、产品特点  Product characteristics

①整线完全全自动化,生产速度快每分钟15-20PCS,工作过程中上料可不停机生产。

The whole line is fully automated, with a production speed of 15-20PCS per minute, and can be produced without shutdown during feeding.

②熔喷可冷压,产品品质可达到FPP3等级

Melt spray can be cold pressed, the product quality can reach FPP3 grade

③自动贴鼻梁，位置精准美观。

Automatic nose bridge, accurate and beautiful position

④设备维护方便，模块化设计，可快速拼接，实现快速生产。

The equipment is easy to maintain, modular design, can be quickly spliced, to achieve rapid production.

⑤设备尺寸小，2700*2000*1800/3500*1500*1800mm占地少方便空运。

The equipment size is small, 2700*2000*1800/3500*1500*1800mm covers an area of less convenient air

transport.

⑥每个模块可单独使用，自由组合。

Each module can be used separately, free combination.

⑦加工件铝合金硬氧处理，机架采用铸铁焊接，烤漆，美观坚固不生锈。

the processing workpiece aluminum alloy hard oxygen processing, the frame adopts cast iron welding,

baking paint, beautiful, solid and not rust.

⑧PLC(三菱PLC)编程控制，稳定性高、故障率低、噪音少。

PLC(Mitsubishi PLC) programming control, high stability, low failure rate, less noise.

⑨采用进口伺服马达，进口气动元件，精度高。

 Adopt imported servo motor, imported pneumatic components, high precision.

⑩用料尺寸小，光电检测原料，避免失误减少浪费。

The material size is small, photoelectric detection of raw materials, avoid mistakes and reduce waste.

⑪机台采用滑轮及固定脚，移动方便快捷，固定性强，不动摇.

The machine adopts pulley and fixed foot, which is convenient and fast to move, strong and fixed, and

does not waver.

3.技术参数 Technical parameters

   ①机器尺寸长宽高：6000mm*2050mm*1800mm 可拆分为2700*2000*1800/3500*1500*1800mm两部分

Machine size length width height: 6000mm*2050mm*1800mm can be split into

2700*2500*1800/3500*2300*1800mm two parts

②重量：总重  2.8T 拆分后 1.3T/1.5T

Weight: Total weight 2.8T 1.3T/1.5T after splitting

③电压： AC380V   50-60HZ

Voltage: AC380V 50-60Hz

④ 生产效率：15-20片/分

Production efficiency: 15-20 pieces/min

⑤功率：20KW

Power: 20KW

⑥耗气量：35m³/min 气压0.6MPa（适配22KW空压机）

Air consumption: 35m³/min Air pressure 0.6Mpa (suitable for 22KW air compressor)
